OVERVIEW
Specification:
| Capacity | 1600 Gms (By Brass pendulum only |
| 3200 Gms (By adding Augmenting weights at the back) | |
| 6400 Gms (By adding Augmenting weights at the front) | |
| Clamping surface of each Clamp | 35.5 mm length x 15.5 mm width |
| Distance between clamps | 2.5±0.25mm |
| Tearing Distance | 43±1mm |
| Slit Size | 20 mm |
| Scale reading | 0 to 100% of range |
| Calibration check weight | At 1600 Gms |
| At 3200 Gms | |
| At 6400 Gms. | |
| Overall Dimensions of Unit | 470(W) x 300(D) x410(H) mm |
| Net wt of the Unit (With check Wt-1600, 3200&6400 Gms) | 29.5Kg. |
We are a manufacturer of testing equipment and we have international standard infrastructure to support this manufacturing. Please refer about page to see our manufacturing facility.
We manufacture and facilitate our products in domestic and international market by exporting to more than 50 countries.
Yes, we do offer maintenance and calibration service. Please contact our service team for further guidance.
Yes, we extend our self to help our customers to fulfill their requirements by providing customization if require and also, we do have many specialized products in our portfolio.
